Camera Modules

vidicon.simple

Feature Preview:

Original Video

Vidicon Module Output

I/O: video/video

Supports HDR: yes

Parameters:

• Input black level (blacklvl): number between 0.0 (dark black) and 1.0 (bright white) that represents the nominal black level for your input video.
• Input white level (whitelvl): number between 0.0 (dark black) and 1.0 (bright white) that represents the nominal white level for your input video.
• Red channel capacitance (r): logarithmically scaled, any number greater than or equal to 1.0. For each +1.0 increase in this parameter, the emulated capacitance for red filtered light doubles.
• Green channel capacitance (g): logarithmically scaled, any number greater than or equal to 1.0. For each +1.0 increase in this parameter, the emulated capacitance for green filtered light doubles.
• Blue channel capacitance (b): logarithmically scaled, any number greater than or equal to 1.0. For each +1.0 increase in this parameter, the emulated capacitance for blue filtered light doubles.
• Decay threshold (thresh): arbitrary parameter representing how susceptible the photochemical screen of the camera is to ghosting due to capacitance. Recommended range of values is anything between or including 0.6 and 0.8.

Animated Examples:

Lower whitelvl

Higher whitelvl

Parameter r in isolation

Parameter g in isolation

Parameter b in isolation
